EZ RAD PRO Concretto Shielded GPR

See inside walls in detail with a 2000MHz central frequency!

Concretto is a lightweight, portable and sturdy

Wall Penetrating Radar (WPR) - an indispensable tool for every construction worker, inspector or repairman.

Excellent penetration depth in concrete and brick floors and walls.

Know where to drill without damaging the structure or your equipment.

Quickly assess the stability of a wall, road or bridge.

Find rebar, wires, cables and pipes on the spot.

The Concretto is an Ultra-Wideband (UWB) shielded pulsed Wall Probing Radar (WPR) for non-destructive imaging of subsurface structures. It comprises of a transmitter and receiver boards and antennae, a controller board and a distance measurement device.

The Concretto has a wide variety of usages including but not limited to underground utility detection, non-destructive concrete structure analysis, rebar detection, road inspection, cracks and faults localization in concrete and asphalt structures, wire and pipe mapping in buildings, etc. It is designed to withstand the harsh conditions of construction sites.
